XPRESS YORKSHIRE PRESS-FIT COPPER PARTIAL CROSSOVER

Xpress YORKSHIRE Press-Fit COPPER PARTIAL CROSSOVER

At Plumb Parts our Xpress Yorkshire Press-Fit Fittings are available from 12mm to 108mm.

Our Range of  Xpress Yorkshire Press-Fit Fittings includes Xpress Yorkshire Press-Fit Copper Straight Couplers, Xpress Yorkshire Press-Fit Copper Reducing Couplers, Xpress Yorkshire Press-Fit Copper Straight Coupling Slips, Xpress Yorkshire Press-Fit Copper Straight Female Connectors, Xpress Yorkshire Press-Fit Copper Straight Male Connectors, Xpress Yorkshire Press-Fit Copper Male Reducers, Xpress Yorkshire Press-Fit Copper Female Adaptors, Xpress Yorkshire Press-Fit Copper Male Adaptors, Xpress Yorkshire Press-Fit Copper Union Coupling, Xpress Yorkshire Press-Fit Copper Equal Elbows,Xpress Yorkshire Press-Fit Copper Reduced Elbows, Xpress Yorkshire Press-Fit Copper Street Elbows, Xpress Yorkshire Press-Fit Copper Knuckle Elbows, Xpress Yorkshire Press-Fit Copper Male Elbows, Xpress Yorkshire Press-Fit Copper Female Elbows, Xpress Yorkshire Press-Fit Copper Back plate Elbows, Xpress Yorkshire Press-Fit Copper Long Pattern BackPlate Elbows, Xpress Yorkshire Press-Fit Copper 90deg Bends, Xpress Yorkshire Press-Fit Copper 45 deg Elbows, Xpress Yorkshire Press-Fit Copper Obtuse Street Elbows, Xpress Yorkshire Press-Fit Copper Crossover, Xpress Yorkshire Press-Fit Copper Partial Crossovers, Xpress Yorkshire Press-Fit Copper Full Crossovers, Xpress Yorkshire Press-Fit Copper Equal Tees, Xpress Yorkshire Press-Fit Copper Reduced Branch tees, Xpress Yorkshire Press-Fit Copper One End Reduced Tees, Xpress Yorkshire Press-Fit Copper One End Reduced And End Branch reduced Tees, Xpress Yorkshire Press-Fit Copper Both End Reduced Tees, Xpress Yorkshire Press-Fit  Copper Copper Female Branch Tees, Xpress Yorkshire Press-Fit Copper Multi Port Female Branch Tees, Xpress Yorkshire Press-Fit Copper Stop Ends, Xpress Yorkshire Press-Fit Copper Unions, Xpress Yorkshire Press-Fit Copper Straight Male Union Connectors, Xpress Yorkshire Press-Fit Copper Straight Female Union Connectors.

The ideal no-fuss solution for domestic, commercial and industrial applications, Xpress Copper combines high performance with a rapid, heat-free installation technique in order to deliver a complete system solution.

Key Features Of Xpress Yorkshire Press-Fit Fittings:

• BSI Kitemark approved (BS 8537:2010)
• Temperature rating from -20°C to 110°C
• Pressure rating 16 bar across the temperature range
• Unique Leak Before Press feature ensure any unpressed fittings are identified upon testing
• Wide range of British and International approvals
• Rapid jointing technique ensures time and labour saving compared to traditional jointing methods
• Heat free jointing – no hot works permits or insurance required

Specification

• Brand: Pegler Yorkshire
• Range: Xpress Copper (water)
• Maker code: S22/7086
• Material: Copper
• Connection: Press Fit end with a male end
• Sizes: 15mm, 22mm and 28mm
• Standard or approval: BS EN 1254-7 (BSI Kitemark KM 789225)
• Max pressure: 16 bar
• Suitable for: Water services on hard and half-hard copper tube

Common Questions

When is a partial crossover the right choice?

When a run only needs to step over another pipe on one side, for example near a manifold. It has one male end that goes into a press socket.

Does the male end need pressing?

The male end is pressed by the socket of the fitting it goes into, not on its own. Mark the depth and push it fully home first.

Is the partial crossover made in 15mm?

Yes, in 15mm, 22mm and 28mm on this listing.
