JG Speedfit Barrier Pipe Straight 22mm x 6m

The JG Speedfit Barrier Pipe Straight 22mm x 6m is a long straight length of 22mm PE-X barrier pipe for plumbers and heating engineers running heating flow and return, a cold main to a combi, or the main hot and cold runs in a bigger house.

Six metres covers a long hall or a loft crossing with no joint in the middle, and because it has never been coiled it stays straight on the clips. The pipe is white cross-linked polyethylene with five layers and a blue oxygen barrier in the centre, which keeps air out of heating water. It’s made to BS 7291 and carries a WRAS approval.

The JG Speedfit Barrier Pipe Straight 22mm x 6m joins with 22mm Speedfit push-fit fittings and a 22mm insert in every end, or a standard insert into compression. The two things most folk get wrong are clip spacing and insertion depth: Speedfit suggest a clip every 500mm on horizontal 22mm and 800mm on vertical, and the pipe stop in a 22mm fitting is 35mm in. Tees, elbows and reducers in 22mm are in our JG Speedfit fittings and pipe section.

Specification

• Brand: JG Speedfit
• Range: Speedfit Barrier Pipe (BPEX)
• Maker code: 22BPEX-20X6L
• Material: Cross-linked polyethylene (PE-X), five layers with oxygen barrier, white
• Connection: Speedfit push-fit fittings with 22mm inserts
• Sizes: 22mm x 6m straight length
• Standard/approval: WRAS approved; Kitemarked to BS 7291 Parts 1, 2 and 3 Class S (KM39767)
• Max pressure: 12.5 bar cold water at 20°C, 6 bar hot water, 3 bar central heating
• Max temperature: 92°C hot water; 95°C short term on central heating
• Suitable for: Hot and cold water, vented and sealed central heating
• Guarantee: 50 years against material and manufacturing defects (T&Cs apply)

Common Questions

How tight can I bend it? Held with clips either side of the curve, the smallest radius Speedfit give for 22mm PE-X is 225mm. Go tighter than that and you should fit an elbow. Never heat the pipe to help it bend.

Does plastic pipe expand when it’s hot? Yes, by about 1% of its length as it warms from 20°C to 82°C. On long exposed runs that can show as sagging between clips, so clip at the right spacing or box the run in.

Can it connect straight onto a boiler? No. Speedfit want at least a metre of copper run from the boiler casing before you change to plastic, unless the boiler maker’s instructions say otherwise. A gravity primary on a solid fuel range should be copper throughout.

How much heat will 22mm pipe carry? Speedfit’s sizing table puts 22mm at about 13.6kW, based on a flow speed of 1.2m/s and an 11°C drop. Use that as a rough guide when you plan how many radiators a run can feed.

Call in at 555 South Street, Glasgow G14 0QX, or order online and collect. Open Mon-Fri 8am-5pm, Sat-Sun 8am-1pm.

Datasheets

• JG Speedfit White PEX Barrier Pipe Length Data Sheet (PDF)
