Copper Pipe 35mm

Once a job outgrows 28mm, Copper Pipe 35mm is the next step up. It’s the size you’ll see on bigger boilers, plant room headers, commercial cold mains and the risers in blocks of flats. We supply it in 1m, 2m, 3m and 6m lengths.

35mm suits heating primaries on larger systems, low loss header connections, gas runs sized for higher loads, and water distribution in shops, schools and offices. Read the markings on the tube if the spec calls for a particular grade.

Copper pipe 35mm lengths

• 1m
• 2m
• 3m
• 6m

All 35mm lengths are Delivered Free in Glasgow or counter collection.

At this size most installers use Press Fit fittings or End Feed. Compression fittings are made in 35mm, though they need a good spanner and plenty of care. If you’re soldering, it takes a lot more heat than small bore, so a bigger torch tip and clean, well-fluxed joints make all the difference. Use a proper large-capacity cutter, deburr inside and out, and support the pipe well, since a full 35mm run of water is heavy. Bending by hand isn’t realistic here, so plan in elbows and bends.

You’ll likely also need 35mm clips, fittings, reducers down to 28mm or 22mm, and insulation for any exposed runs. See the rest of our copper pipe for other sizes.

Getting 35mm copper tube in Glasgow

35mm copper lengths are collected from Plumb Parts, 555 South Street, Glasgow G14 0QX during Mon-Fri 8am-5pm or Sat-Sun 8am-1pm, or bought online.

Specification

• Material: Copper
• Sizes: 35mm, in 1m, 2m, 3m or 6m lengths
• Suitable for: Larger boilers, headers and commercial cold mains

Common Questions

How do I cut 35mm copper pipe? Use a large tube cutter so the end stays square and round, then ream the burr off the inside. A hacksaw leaves a rough end that is hard to joint well.

Can you bend 35mm copper pipe? Not really on site, as standard 35mm tube has a heavier 1.2mm wall and is too stiff. Plan your changes of direction with bends and elbows instead.

Can 35mm copper pipe be used for a gas supply? Yes, copper tube to BS EN 1057 is used for gas and 35mm is common on bigger commercial supplies. Any gas work must be designed and fitted by a Gas Safe registered engineer.

What is 35mm copper pipe used for? It is the first of the commercial sizes, the step up once a job outgrows 28mm. You see it on larger boilers, plant room headers, cold water risers in flats and bigger gas supplies.

Can you solder 35mm copper pipe? Yes, with end feed fittings, though you need a bigger torch and well cleaned, well fluxed joints. Many installers go with press fittings at this size instead, as there is no flame and no hot works permit.

What wall thickness is 35mm copper tube? Standard UK tube to BS EN 1057 has a 1.2mm wall in 35mm. Heavier grades are made too, so check the printing on the tube against the job spec.

What length does 35mm copper pipe come in? It comes in 3m lengths, and those are for collection over the counter at our South Street shop only.
