Danfoss Motorised Valve 2 Port and 3 Port 15mm to 28mm

The Danfoss Motorised Valve controls the flow to heating and hot water when the programmer or thermostat calls for it. We sell the HP22 and HP28 2 port valves in 22mm and 28mm (shoe type, or paddle type B), the HS3 and HS3B 3 port mid position valves in 15mm, 22mm, 28mm, 3/4 inch BSP and 1 inch BSP, the HPA2, HPA2C, HSA3 and HSA3D actuator heads, and the HPV22 2 port body on its own.

The HP22 is spring return, so it shuts when the power is off. The 3 port valves sit where the flow splits on a Y plan system and send water to heating, hot water or both. Danfoss make two body types: the HS3 has a rotary shoe and the HS3B ones have a paddle, so match the code on your old body when you only need a part. The heads lift off the body without draining the system, and the C head has a changeover switch, while the D head is for a diverter valve.

The valve runs on mains voltage. Isolate the supply and wire it to the system diagram, or have a competent heating engineer do it.

Specification

• Brand: Danfoss
• Maker code: HP22 087N6609 (2 Port x 22mm), HP22B 087N6642 (2 Port x 22mm Paddle Type), HP28 087N6611 (2 Port x 28mm), HP28B 087N6644 (2 Port x 28mm Paddle Type), HPV22 087N6597 (2 port body only, 22mm), HS3B15 087N6650 (3 Port x 15mm), HS3B 087N6646 (3 Port x 22mm), HS3 087N6613 (3 Port x 22mm shoe type), HS3B28 087N6651 (3 Port x 28mm), HS3B0.75 087N6648 (3 Port x 3/4 Inch BSP), HS3B1.0 087N6649 (3 Port x 1 Inch BSP), HPA2 087N6579, HPA2C 087N6580, HSA3 087N6587, HSA3D 087N6589
• Type: 2 port spring return to closed, 3 port mid position, replacement actuators
• Connection: Compression (15mm, 22mm, 28mm) or BSP (3/4 and 1 inch)
• Power supply: 230V AC 50/60Hz, 6W
• Auxiliary switch: 3(1)A 220/240V, changeover on HPA2C
• Maximum working pressure: 10 bar
• Maximum water temperature: 95°C
• Maximum differential pressure: 1.0 bar (22mm), 0.7 bar (28mm)
• Enclosure: IP40
• Sizes: 2 Port x 22mm, 2 Port x 22mm Paddle Type, 2 Port x 28mm, 2 Port x 28mm Paddle Type, 3 Port x 15mm, 3 Port x 22mm, 3 Port x 22mm Shoe Type, 3 Port x 28mm, 3 Port x 3/4 Inch BSP, 3 Port x 1 Inch BSP, 2 Port Replacement Head, 2 Port Replacement Head Changeover Switch, 3 Port Mid Position Replacement Head, 3 Port Diverter Replacement Head, 2 Port Valve Body Only x 22mm

Common Questions

Do I need a 2 port or a 3 port valve?

Go by the system you have. Separate valves on the heating and hot water legs is an S plan, so 2 port. One valve where the flow splits is a Y plan, so 3 port mid position.

What is the difference between HS3 and HS3B?

Danfoss use a rotary shoe inside the HS3 and a paddle inside the B models. Both are 3 port mid position valves, but the heads and bodies are matched, so go by the code on the old valve.

Can I collect a Danfoss motorised valve today in Glasgow?

Yes. Order online and use free Click and Collect at 555 South Street, Glasgow G14 0QX, open Mon-Fri 8am-5pm and Sat-Sun 8am-1pm.
