FloPlast MDPE Male Coupler 20mm to 32mm

Going from MDPE pipe into a female thread is a job for the FloPlast MDPE male coupler. It grips the blue pipe on one end and gives you a male BSP thread on the other.

Jobs for the FloPlast MDPE male coupler

It screws into female threaded valves, tank connectors, water meters and brass fittings. So it often turns up on garden taps, feeds to a garage or shed, and where new MDPE joins old pipework. It is a cold water fitting.

• 20mm with 1/2 inch or 3/4 inch male thread
• 25mm with 3/4 inch or 1 inch male thread
• 32mm with 3/4 inch or 1 inch male thread
• Plastic coupler for MDPE pipe

Do the threaded end first, using PTFE tape on the male thread, and do not over tighten plastic into brass. Then prepare the pipe. Cut it square, fit a liner, slacken the nut and push the pipe fully home. Do the nut up by hand. Before you bury anything, put the supply under pressure and check every joint is dry.

Buying MDPE couplers in Glasgow

The female version and other fittings are in our MDPE and alkathene fittings.

Plumb Parts is on 555 South Street, Glasgow G14 0QX. Drop in Mon-Fri 8am-5pm or Sat-Sun 8am-1pm, or order through the website.

Specification

• Brand: FloPlast
• Range: MDPE fittings
• Maker code: 491102 (20mm x 1/2″), 493302 (32mm x1″)
• Connection: Nut and grip for MDPE pipe, male BSP thread
• Sizes: 20mm x 1/2″, 20mm x 3/4″, 25mm x 3/4″, 25mm x 1″, 32mm x 3/4″ and 32mm x 1″
• Suitable for: Cold water supply in blue MDPE pipe

Common Questions

Can a plastic male coupler go into a brass fitting?

Yes, but do not overtighten it, because a plastic thread can split inside brass. A few turns of PTFE tape and a firm hand tighten is enough.

Which size do I need for a 32mm main into a 1 inch valve?

The 32mm x 1″ male coupler. The listing also has a 32mm x 3/4″ for smaller valve ports.

Datasheets

• FloPlast MDPE Systems Brochure (PDF)
