Compression DZR Reducing Tees 22mm

Each one of the Compression DZR Reducing Tees takes a branch off a run where the pipe sizes do not all match, such as a 15mm leg off a 22mm main. Its DZR brass body is far less prone to dezincification than a standard brass fitting.

Where reducing tees are used

Mixed sizes are everywhere in domestic work. A 22mm heating flow feeding 15mm radiator tails, a 22mm cold main splitting to 15mm for a basin, or a 15mm run picking up a 22mm supply. A proper reducing tee does that in one fitting, with no reducing sets or adaptors, so there are fewer joints and less clutter under the floor.

Sizes available

• 22mm x 22mm x 15mm: 22mm run with a 15mm branch
• 22mm x 15mm x 15mm: 22mm in, 15mm out on both the run and branch
• 15mm x 15mm x 22mm: 15mm run with a 22mm branch

Sizes are read run, run, branch, so double check which end you need before you leave the counter.

Fitting tips from the Glasgow counter

Work out flow direction before you start, especially on the 22 x 15 x 15 pattern where only one end is the larger size. Cut pipe square, deburr, and push fully home. Use two spanners to stop the tee twisting as you tighten each nut.

Equal and female branch tees sit with the Compression DZR Reducing Tees in our DZR Compression tees section.

Call into the Plumb Parts trade counter at 555 South Street, Glasgow G14 0QX. Hours are Mon-Fri 8am-5pm and Sat-Sun 8am-1pm, with online ordering any time.

Specification

• Material: DZR brass
• Connection: reducing tee, Compression on all three ends
• Sizes: 15mm x 15mm x 22mm, 22mm x 15mm x 15mm, 22mm x 22mm x 15mm
• Suitable for: branching off copper water and heating runs where sizes differ

Common Questions

Which DZR reducing tee takes a 15mm radiator feed off a 22mm flow?

Pick the 22mm x 22mm x 15mm: full size through, with only the branch reduced to suit the radiator.

What is the 22mm x 15mm x 15mm for?

Here 22mm enters one end and both outlets, straight through and branch, leave in 15mm. That suits the tail end of a run feeding two outlets.

Can I use one of these on a mains cold supply?

Yes, and DZR brass is a good match for mains water, where it will stay full of water for years.
