Compression DZR Single Part Reducer 22mm to 28mm

Simple and quick to fit, a Compression DZR Single Part Reducer is a one-piece insert that converts the port of a bigger Compression fitting to take a smaller pipe. The DZR brass it is made from holds out against dezincification.

How it works

Where a three-piece set has separate bits, this is a single machined insert. You slide it onto the smaller pipe, put it into the larger fitting in place of the olive, and tighten the existing nut. As the nut goes down, the reducer grips the smaller pipe and seals in the bigger body. Fewer loose parts means it is quicker and there is less to drop under the floor.

Sizes available

• 28mm x 22mm for reducing a 28mm fitting to take 22mm tube
• 22mm x 15mm for a 15mm pipe into a 22mm fitting

Fitting tips from Glasgow

The larger fitting must be a Compression fitting of the matching size, with its own nut. Make sure the smaller pipe is cut square, deburred and pushed right through to the internal stop before you tighten. Once it is made, the reducer has bitten onto the pipe, so treat it like an olive: if you take the joint apart, expect to cut back and fit a new one.

Prefer separate parts? The three-piece set sits next to the Compression DZR Single Part Reducer under Compression DZR fittings.

Get one over the Plumb Parts counter, 555 South Street, Glasgow G14 0QX, open Mon-Fri 8am-5pm plus Sat-Sun 8am-1pm. Ordering online works as well.

Specification

• Material: DZR brass
• Connection: one piece insert for a larger Compression port
• Sizes: 22mm x 15mm, 28mm x 22mm
• Suitable for: letting a larger Compression fitting take a smaller pipe

Common Questions

Single part reducer or three piece set: what is the difference?

The single part reducer is one machined insert, so there is less to lose and it is quicker to fit. The three piece set has separate parts but does the same job.

Can a single part reducer be taken out and used again?

Not really. Once tightened it grips the smaller pipe like an olive, so plan to cut back and fit a new one if the joint is remade.

Which nut tightens it?

The existing nut of the larger fitting. The reducer goes in where the large olive would sit and the nut pulls it down.
