FloPlast MDPE Reducing Tee 25mm to 32mm

The FloPlast MDPE Reducing Tee lets you split an underground cold water supply and drop down a size on the branch. The run goes straight through, and the side outlet is one size smaller.

Where a FloPlast MDPE Reducing Tee fits in

Think of a 25mm supply coming up the garden with a 20mm leg peeling off to a garage, a stand pipe or a second property. The 32mm version does the same job on a bigger main with a 25mm take off. Each end has a nut that you tighten down by hand, so no special tools are needed, and the joints can be taken apart again later.

• Sizes: 25mm x 25mm x 20mm and 32mm x 32mm x 25mm
• For MDPE polyethylene water pipe
• Compression nut and seal on every end, tightened by hand
• Used on cold mains water, often below ground

Cut the pipe square and take off any burr. Most installers push a liner or insert into the pipe end before making the joint, because it keeps the soft pipe round under the seal. Push the pipe in past the grab ring until it bottoms out, then nip the nut up. Test before you backfill the trench. More MDPE bits sit in our MDPE and Alkathene Fittings range.

Getting MDPE fittings in Glasgow

Drop into Plumb Parts at 555 South Street, Glasgow G14 0QX. The doors are open Monday to Friday 8am to 5pm, Saturday and Sunday 8am to 1pm, and the online shop never closes.

Specification

• Brand: FloPlast
• Maker code: 492125 (25mm x 25mm x 20mm), 493225 (32mm x 32mm x 25mm)
• Connection: Hand tightened Compression nut on each end
• Sizes: 25mm x 25mm x 20mm and 32mm x 32mm x 25mm
• Suitable for: MDPE cold water supply pipe

Common Questions

Do I need liners in MDPE before fitting the tee?

Most installers fit a liner or insert in each pipe end. It keeps the pipe round under the seal, which matters on buried supplies.

Which way round does the reducing tee go?

The two big ends sit on the main run and the smaller branch takes the take off. For example, run 25mm through and branch off in 20mm.

Can these MDPE joints be buried?

MDPE fittings like this are used below ground on cold supplies. Bed them in sand, test before backfilling, and keep the depth the water authority asks for.

Datasheets

• FloPlast MDPE Systems Brochure (PDF)
