FloPlast Ring Seal 92.5 Deg Access Bend – SP169 110mm
£28.00 inc VAT (£23.33 ex VAT)
✓ In Stock
Free Click and Collect, no minimum order, from our Glasgow counter at 555 South Street, G14 0QX. Open Mon-Fri 8am-5pm, Sat-Sun 8am-1pm.
Delivery: free UK mainland delivery on orders over £250, or £12 + VAT under £250. In stock orders placed by 2pm Monday to Friday usually go out for next working day delivery. Returns: 14 days. Call 0141 404 5128 for a return number first. Delivery and Returns
Trade and public welcome at 555 South Street, Glasgow G14 0QX. Call 0141 404 5128.
The FloPlast Ring Seal 92.5 Deg Access Bend SP169 combines a 110mm soil bend with a rodding door for the foot of a stack. Black, white or grey, and kept at Plumb Parts in Glasgow.
| SKU | Thumbnail | Size | Colour | Price | Quantity | Total | ||
|---|---|---|---|---|---|---|---|---|
| SP169 |
|
110mm | Black | £28.00 inc VAT (£23.33 ex VAT) |
-
+
|
£28.00 inc VAT | ||
| SP169 |
|
110mm | White | £28.00 inc VAT (£23.33 ex VAT) |
-
+
|
£28.00 inc VAT | ||
| SP169 |
|
110mm | Grey | £28.00 inc VAT (£23.33 ex VAT) |
-
+
|
£28.00 inc VAT |
At the foot of a soil stack, the FloPlast Ring Seal 92.5 Deg Access Bend SP169 turns the pipe and gives you a removable access door in the same fitting. It suits 110mm Ring Seal soil pipe.
Why fit the FloPlast Ring Seal 92.5 Deg Access Bend SP169
The bottom of a stack is where blockages tend to build up, and it is also where a drain rod needs to get in. With an access bend, the rodding door sits exactly where it is wanted, without a separate access pipe taking up space.
Turn the access door so it faces somewhere it can be reached once the job is finished, not into a wall or under a floor. Chamfer cut pipe ends, lubricate with silicone and push the joints fully home.
Fit the door seal carefully and tighten its fixings evenly, so it does not leak under test.
Clip the stack firmly above the bend, since this fitting carries the weight of the pipe above.
Access bends at our Glasgow counter
Branches and straight pipe to suit sit in the Flexible range, so you can sort the whole stack in one go. Plumb Parts at 555 South Street, Glasgow G14 0QX, opens Mon-Fri 8am-5pm and Sat-Sun 8am-1pm, or you can order online.
Specification
- Brand: FloPlast
- Range: 110mm Ring Seal Soil
- Maker code: SP169
- Material: PVC-U
- Connection: Ring Seal joints with a removable access door
- Sizes: 110mm
- Standard or approval: BS EN 1329-1 and BS EN 1453-1, Kitemark KM 544331
- Max temperature: 70°C to 75°C continuous; hotter discharges for 2 minutes at most
- Suitable for: Rodding access at the foot of a soil stack
Common Questions
Why put the access door at the foot of the stack?
Blockages tend to build up at the bottom, and that is where a rod needs to go in. The SP169 puts the door exactly there without a separate access pipe.
What should be checked on the access door before a test?
Make sure the door seal is clean and sitting flat. Work round the fixings evenly so the door pulls down square and does not leak under test.
Does the SP169 need extra support?
Yes, it carries the weight of the stack above. Bracket the pipe firmly just above the bend so the fitting is not pushed down.
Datasheets
| Size |
110mm |
|---|---|
| Colour |
Black ,White ,Grey |
