FloPlast Solvent Soil Double Socket 92.5° Bend – SS561 110mm

Near-square turns on glued soil runs use the FloPlast Solvent Soil Double Socket 92.5° Bend SS561, which turns a 110mm solvent soil pipe through just over a right angle. Both ends are solvent sockets.

Where the FloPlast Solvent Soil Double Socket 92.5° Bend SS561 goes

The extra few degrees over 90 give a horizontal run a slight fall where it leaves a vertical drop. It is common at stack bases, beneath floors and wherever a WC run swings round a corner.

Use plain-ended pipe on both sides. Dry fit, check the fall goes the right way, and mark the joints. Then apply solvent cement to each pair of surfaces, push home and hold.

At the foot of a stack this bend takes a lot of weight, so support it with a bracket or proper bedding.

Put an access point near the bend, as blockages tend to collect at changes of direction. A quick water test before backfilling or boxing in saves a lot of grief.

Soil bends at our Glasgow counter

Access pipes and straight lengths to go with it are in the Flexible range, or you can swing by Plumb Parts at 555 South Street, Glasgow G14 0QX, during Mon-Fri 8am-5pm and Sat-Sun 8am-1pm, or order on the website for collection.

Specification

• Brand: FloPlast
• Range: 110mm Solvent Soil
• Maker code: SS561
• Material: PVC-U
• Connection: Solvent sockets both ends, 92.5 degrees
• Sizes: 110mm
• Standard or approval: BS EN 1329-1 and BS EN 1453-1, Kitemark KM 544331
• Max temperature: 70°C to 75°C continuous; hotter discharges for 2 minutes at most
• Suitable for: Turns under floors and on WC runs

Common Questions

What goes into each end of the SS561?

Plain soil pipe or a fitting spigot, glued with solvent cement. Both ends are sockets.

Is this range for underground use?

No, it is FloPlast’s above ground solvent soil. Below ground runs need their underground drainage fittings.

Is there a version with a rodding door?

Yes. The SS569 access bend has one, which suits the foot of a stack.
