Flush Valve Long Cable

This flush valve long cable version suits cisterns where the push button is mounted well away from the valve itself. A longer cable reaches the button without stretching or binding, so the flush works cleanly every time.

Where a flush valve long cable helps

Cable operated valves are often used where the button sits on the side or front of a unit rather than straight above the valve. A short cable pulled tight will not flush properly. The longer cable gives room to route it neatly.

• Cable operated dual flush valve with long cable
• Chrome-on-plastic dual flush push button
• Volume adjusts, with an overflow inside the valve
• Bolts, seals, nuts and a doughnut supplied

Run the cable in gentle curves with no tight kinks, because sharp bends make the button stiff. Fix the button first, then fit the valve and connect the cable so it has a little slack. Set the flush volume, and check that both the half and full flush lift the valve fully.

If it is a close coupled cistern, tighten the cistern bolts evenly so the new doughnut sits square.

Spare flush buttons and other flush valves can be found in our cistern fittings section.

Cable flush valves in Glasgow

Visit the counter at Plumb Parts, 555 South Street, Glasgow G14 0QX. Hours are Mon-Fri 8am-5pm and Sat-Sun 8am-1pm, or shop online.

Specification

• Connection: cable operated, with a long cable to the push button
• Suitable for: dual flush cisterns where the button sits away from the valve

Common Questions

When do I need a long cable flush valve?

When the flush button is mounted away from the valve, for example on the side or front of a unit, so a short cable or push rod cannot reach it without being pulled tight.

Why is the button stiff after fitting?

Tight bends in the cable cause drag. Reroute it in gentle curves and check it is not trapped by the lid or a panel.

Does it give a half flush and a full flush?

Yes, it is a dual flush valve, so the button has a part for each. Once fitted, press both and check each one lifts the valve fully.
