Compression Chrome Plated Reducing Coupler 15mm to 22mm

Compression Chrome Plated Reducing Coupler

Compression Chrome Plated Reducing Coupler used to connect two pipes or tubes of different diameters.

Chrome Compression Fittings

Chrome Compression fittings are especially advantageous in retrofit plumbing schemes, where space is confined and/or the use of heat must be avoided.

They are available in 6-108mm and are suitable for connecting tubes in accordance with EN 1057 and many other standards including ISO 274.

At Plumb Parts our range of Chrome Compression fittings are suitable for a broad spectrum of applications across the domestic, industrial and commercial sectors.

These types of Compression fittings are an easy to use the heat-free system, and excellent for repairs, and in applications where ongoing maintenance is envisaged

Compression fittings are available in duplex brass and/or dezincification resistant (DZR) brass or as dezincification immune gunmetal.

Fittings are also available nickel-plated or chrome-plated in accordance with EN 248.

Chrome Plated Compression fittings are suitable for connecting a wide range of tubes including copper tubes in accordance with EN 1057 and many other standards including ISO 274.

Fittings are also compatible with connecting low carbon steel, stainless steel and many types of plastic pipe including crossed linked polyethylene (PE-X) and polybutylene (PB) with size compatible outside diameters.

At Plumb Parts in Glasgow, our range of Chrome Plated Compression Fittings includes:

Straight Couplers , Reducing Couplers , Male Couplers , Female Couplers , Elbows 90 deg ,  Wallplate Elbows , Long Radius Elbows , Angled Wallplate Adaptors ,Stop Ends, Straight Tap Connectors , Bent Tap Connectors , Tees , Reduced Branch Tee , Both Ends Reduced Tee , Reduced End Tee , Reduced End and Branch Tee ,  Straight Cylinder Union , Bent Cylinder Union

Available as single units or individually bagged.

Specification

• Material: chrome plated
• Connection: reducing, larger Compression end x smaller Compression end
• Sizes: 15mm x 8mm, 15mm x 10mm, 15mm x 12mm, 22mm x 15mm, 28mm x 22mm
• Suitable for: stepping visible pipe down a size in a straight line

Common Questions

Which way round does a reducing coupler go?

Either way, as long as each end takes the right pipe. The bigger end goes on the larger pipe, for example 22mm, and the smaller end takes the 15mm.

What would I use the 15mm x 12mm for?

It joins 12mm pipe, found on some older or imported installations, onto standard 15mm copper.

Can the small end take plastic microbore?

Yes, with the insert the pipe maker specifies pushed into the plastic pipe beforehand. Without it the olive squashes the soft pipe.
