FloPlast Solvent Soil Single Socket Coupler – SS107 110mm
£5.20 inc VAT (£4.33 ex VAT)
✓ In Stock
Free Click and Collect, no minimum order, from our Glasgow counter at 555 South Street, G14 0QX. Open Mon-Fri 8am-5pm, Sat-Sun 8am-1pm.
Delivery: free UK mainland delivery on orders over £250, or £12 + VAT under £250. In stock orders placed by 2pm Monday to Friday usually go out for next working day delivery. Returns: 14 days. Call 0141 404 5128 for a return number first. Delivery and Returns
Trade and public welcome at 555 South Street, Glasgow G14 0QX. Call 0141 404 5128.
Glue on one end and a sealed push joint on the other: the FloPlast Solvent Soil Single Socket Coupler SS107 lets a 110mm glued stack move. Black or olive grey, from Plumb Parts in Glasgow.
| SKU | Thumbnail | Size | Colour | Price | Quantity | Total | ||
|---|---|---|---|---|---|---|---|---|
| SS107 |
|
110mm | Black | £5.20 inc VAT (£4.33 ex VAT) |
-
+
|
£5.20 inc VAT | ||
| SS107 |
|
110mm | Olive Grey | £5.20 inc VAT (£4.33 ex VAT) |
-
+
|
£5.20 inc VAT |
Allowing for movement in a glued stack is easy with the FloPlast Solvent Soil Single Socket Coupler SS107, a 110mm soil coupling with a solvent socket at one end and a Ring Seal socket at the other.
Why use the FloPlast Solvent Soil Single Socket Coupler SS107
A Solvent Weld soil stack is rigid, and PVC-U grows and shrinks with temperature. A Ring Seal joint gives the pipe room to move. Glue one end onto the pipe and push the next pipe into the Ring Seal end.
Use solvent cement on the solvent end only and silicone lubricant on the Ring Seal end. Chamfer the pipe going into the Ring Seal and push it home, then ease back slightly.
Fit a clip near the coupler so any movement happens at the seal, not at the glued joint.
It also links a glued stack to Ring Seal soil pipe if a job uses both. Mark the insertion depth on the Ring Seal pipe so you can see later whether it has moved.
Single socket couplers in Glasgow
Bends and pipe to finish the stack sit in our Flexible range. Plumb Parts trades at 555 South Street, Glasgow G14 0QX, Mon-Fri 8am-5pm and Sat-Sun 8am-1pm, or you can buy online.
Specification
- Brand: FloPlast
- Range: 110mm Solvent Soil
- Maker code: SS107
- Material: PVC-U
- Connection: Solvent socket one end, Ring Seal socket the other
- Sizes: 110mm
- Standard or approval: BS EN 1329-1 and BS EN 1453-1, Kitemark KM 544331
- Max temperature: 70°C to 75°C continuous; hotter discharges for 2 minutes at most
- Suitable for: Expansion points on glued stacks, and linking to Ring Seal pipe
Common Questions
What does the SS107 coupler do? It joins 110mm soil pipe in a straight line, with a solvent socket on one end and a Ring Seal socket on the other. That makes it ideal as an expansion point in a glued stack.
Can you solvent weld soil pipe? Yes, FloPlast’s 110mm Solvent Soil range is made to be glued, and the solvent end of this coupler bonds straight onto it. The other end is a Ring Seal, which takes lubricant rather than cement.
How do I fit the SS107? Cement the solvent end onto its pipe. For the Ring Seal end, chamfer the next pipe, apply silicone lubricant, push it home and ease it back slightly.
Why does a glued stack need an expansion joint? PVC-U grows and shrinks as it warms and cools, and a fully glued stack has nowhere to move. FloPlast’s fixing guide asks for an expansion joint every 4 metres.
Can it connect solvent soil to Ring Seal soil pipe? Yes, it links the two systems in one fitting, glued on one side and sealed on the other.
Where should I put the clip? Fit a clip near the coupler so any movement happens at the seal rather than the glued joint. Marking the insertion depth on the pipe lets you see later if it has shifted.
Can it handle hot water? It’s rated for 70°C to 75°C continuous, with hotter discharges for no more than 2 minutes.
Datasheets
| Size | 110mm |
|---|---|
| Colour | Black, Olive Grey |
