Hep2O End Reducing Tee 22mm to 28mm
Price range: £4.45 through £18.94 inc VAT ( Price range: £3.71 through £15.78 ex VAT)
✓ In Stock
Free Click and Collect, no minimum order, from our Glasgow counter at 555 South Street, G14 0QX. Open Mon-Fri 8am-5pm, Sat-Sun 8am-1pm.
Delivery: free UK mainland delivery on orders over £250, or £12 + VAT under £250. In stock orders placed by 2pm Monday to Friday usually go out for next working day delivery. Returns: 14 days. Call 0141 404 5128 for a return number first. Delivery and Returns
Trade and public welcome at 555 South Street, Glasgow G14 0QX. Call 0141 404 5128.
The Hep2O End Reducing Tee drops one end of the run a size while the branch stays full size. Sizes 22mm x 15mm x 22mm and 28mm x 22mm x 28mm, from Plumb Parts in Glasgow.
| SKU | Thumbnail | Sizes | Price | Quantity | Total | ||
|---|---|---|---|---|---|---|---|
| HD1222W |
|
22mm x 15mm x 22mm | £4.45 inc VAT (£3.71 ex VAT) |
-
+
|
£4.45 inc VAT | ||
| HD1228W |
|
28mm x 22mm x 28mm | £18.94 inc VAT (£15.78 ex VAT) |
-
+
|
£18.94 inc VAT |
A Hep2O End Reducing Tee steps down at one end of the run, while the branch and the other end stay at the larger size. It suits a layout where the main pipe turns off through the branch at full size and a smaller pipe carries on straight ahead.
How the Hep2O End Reducing Tee is sized
The sizes read end x end x branch. With 22mm x 15mm x 22mm, the full 22mm flow goes in one end and out through the branch, while a 15mm pipe continues from the reduced end. That 15mm leg might feed a single basin or radiator. With 28mm x 22mm x 28mm, the same idea works one size up, on a larger supply or primary run.
Fit support sleeves in all plastic pipe ends. Seat each pipe fully, then pull back to check it has locked. Clip the pipes near the tee, so the joints are not carrying the pipe runs.
Other reducing tees are in our Hep2O fittings range.
Specification
- Brand: Hep2O
- Maker code: HD12/22W, HD12/28W
- Connection: Push Fit sockets
- Sizes: 22mm x 15mm x 22mm and 28mm x 22mm x 28mm
- Material: Polybutylene body, EPDM O-ring
- Standard or approval: BS 7291 Parts 1 and 2, Class S (Kitemark)
- Max pressure: 12 bar at 20°C
- Max temperature: 95°C at up to 6 bar (114°C short fault only)
- Suitable for: Running the main through the branch with a smaller straight-on leg
- Guarantee: 50 years
Common Questions
When is an end reducing tee better than a branch reducing tee?
When the main pipe turns off through the branch at full size and only the straight-on leg drops a size.
Can I swap the reduced end round?
The tee is symmetrical in use, so it can face either way. Just make sure the small end lines up with the smaller pipe.
Which jobs suit the 28mm end reducing tee?
Larger supplies, such as a 28mm main that turns off to a cylinder while a 22mm leg carries on to other outlets.
Buying Hep2O in Glasgow
Reducing tees are stocked by Plumb Parts at 555 South Street, Glasgow G14 0QX. Counter hours: Monday to Friday 8am to 5pm, Saturday and Sunday 8am to 1pm. Orders also go through online.
Datasheets
| Sizes |
22mm x 15mm x 22mm ,28mm x 22mm x 28mm |
|---|
