Hep2O Male Adaptor 10mm to 28mm
Price range: £5.14 through £12.77 inc VAT ( Price range: £4.28 through £10.64 ex VAT)
✓ In Stock
Free Click and Collect, no minimum order, from our Glasgow counter at 555 South Street, G14 0QX. Open Mon-Fri 8am-5pm, Sat-Sun 8am-1pm.
Delivery: free UK mainland delivery on orders over £250, or £12 + VAT under £250. In stock orders placed by 2pm Monday to Friday usually go out for next working day delivery. Returns: 14 days. Call 0141 404 5128 for a return number first. Delivery and Returns
Trade and public welcome at 555 South Street, Glasgow G14 0QX. Call 0141 404 5128.
The Hep2O Male Adaptor joins Hep2O pipe to a female threaded fitting. Choose 10mm x 1/2″, 15mm x 1/2″, 22mm x 3/4″ or 28mm x 1″ at Plumb Parts, Glasgow.
| SKU | Thumbnail | Size | Price | Quantity | Total | ||
|---|---|---|---|---|---|---|---|
| HEP144 |
|
10mm x 1/2" | £5.14 inc VAT (£4.28 ex VAT) |
-
+
|
£5.14 inc VAT | ||
| HEP145 |
|
15mm x 1/2" | £7.86 inc VAT (£6.55 ex VAT) |
-
+
|
£7.86 inc VAT | ||
| HEP136 |
|
22mm x 3/4" | £11.30 inc VAT (£9.42 ex VAT) |
-
+
|
£11.30 inc VAT | ||
| HEP137 |
|
28mm x 1" | £12.77 inc VAT (£10.64 ex VAT) |
-
+
|
£12.77 inc VAT |
Going from plastic pipe into a threaded valve, cylinder or manifold is simple with a Hep2O Male Adaptor. One end is a Push Fit socket for the pipe, and the other is a male thread that screws into a female fitting.
Hep2O Male Adaptor sizes
The 10mm x 1/2″ size connects microbore pipe to a 1/2″ female fitting, for example on a manifold. 15mm x 1/2″ suits small valves and fittings. 22mm x 3/4″ fits pumps, larger valves and many boiler connections. 28mm x 1″ suits cylinder bosses and bigger supplies.
Screw the male thread into the female socket before you push the pipe in. Use PTFE tape or a jointing compound that is safe for plastics, and tighten it without forcing it. Finally sleeve the pipe end and push it in until it locks. Give it a pull to be sure before the water goes back on.
Female adaptors and brass spigot adaptors are in our Hep2O fittings range.
Specification
- Brand: Hep2O
- Maker code: HX29/10W (10mm x 1/2″), HX29/15W (15mm x 1/2″), HX29/22W (22mm x 3/4″), HX29/28W (28mm x 1″)
- Material: Brass, dezincification resistant
- Connection: Hep2O socket, male BSP thread
- Sizes: 10mm x 1/2″, 15mm x 1/2″, 22mm x 3/4″ and 28mm x 1″
- Suitable for: Connecting Hep2O pipe to female threaded fittings
- Standard/approval: BS 7291 Class S, Kitemarked, WRAS approved
- Max pressure: 12 bar at 20°C, 6 bar at 95°C
- Max temperature: Up to 95°C
- Guarantee: 50 years
Common Questions
Does the male adaptor socket take copper?
Yes, like other Hep2O sockets it takes copper of the same size without an insert.
Can the male adaptor go into a plastic female thread?
Go gently, using PTFE tape and not too much force, as brass in a plastic thread can split the female part.
Is the 10mm x 1/2″ for microbore?
Yes. It takes 10mm microbore straight into a 1/2″ female fitting.
Adaptors at Plumb Parts, Glasgow
Call into 555 South Street, Glasgow G14 0QX during Monday to Friday 8am to 5pm or Saturday and Sunday 8am to 1pm. Online ordering is there too.
